SRT55D
55t Off-highway Dump Truck
Total Power
565 kW
Maximum Torque
3260 NM
Load Weight
55 T

Features

Full views

· 1. Panoramic windshiel with a wider view;

· 2. The blind area of the short locomotive structure is 2 metres shorter than the similar products.Impeccable rearview mirror layout make the operation safer.

Steering mechanism and suspension system

· The reinforced articulated bearing ensures the reliability of the vehicle during steering and bumping.

Hydraulic system

· Advanced hydraulic matching technology, the oil temperature is 5℃ lower than similar products. Independent functional modules will not interfere with each other.

Steering mechanism

· Large steering Angle design which be better than the industry level.

· Strong mobility, operation efficiency significantly improved.

Suspension system

· Suspension cylinder with patented technology, the root mean square value of vibration acceleration is 20% lower than similar domestic products.

· McPherson independent suspension can effectively avoid the eccentric wear caused by the lateral force of the traditional suspension cylinder in the industry, improve the life of the suspension cylinder and reduce the tire wear.

Specs & Compare

Engine Model
Total Power
Maximum Torque
Number/Type Of Cylinders
Displacement
Gearbox Type
Automatic/Manual
Left/Right Hand Drive
Axle
Capacity (Struck/Heaped)
Load Weight
Tyre
Lubrication System
Size
Net Weight
Maximum Gradeability
Minimum Turning Radius
SRT55D
VOLVO TAD1643VE-B
565 kW
3260 NM
6/Straight type
16.1 L
AVITEC H6620AR
Automatic
Left
SANY
26/35 m³
55 T
24.00R35 Radial Tire
Manual/Automatic
9125x4150x4505 mm
40 T
30 %
9540 mm
