SCIM1213RC6
China-Ⅲ Diesel-driven Mobile Impact Crusher
Crushing Strength
<150 MPa
Max. Feeding Size
600 mm
Processing Capacity
150-450 t/h

Features

High Output

· Intelligent feeding and independent pre-screening

· Direct drive of crusher by engine

· Double-chamber structure and high-precision heavy-duty rotor

Low Energy Consumption

· Direct drive system

· Separate setting of traveling/working power

· Adaptive power-saving mode of the system

· With an environmental-friendly spray and dust reduction system

High Reliability

· Imported core components

· Super wear-resistant parts

· High-strength endurance test under full working conditions

Intelligent Control

· Professional controller, touch screen control, one-click operation, and platform-based operation management.

Specs & Compare

Crushing Strength
Max. Feeding Size
Processing Capacity
Engine Power
Rated Power of the Whole Machine
L x W x H
Transportation Weight of the Whole Machine
Operating Mode
SCIM1213RC6
<150 MPa
600 mm
150-450 t/h
371/1800 kW/rpm
330 kW
21800x3400x3900 mm
67 T
1-button touch screen operation
