HZS180F8
F Series 180m³/h Concrete Batching Plant
Aggregate Capacity
4×25 m³
Nominal Capacity of Mixer
3000 L
Theoretic Productivity
180 m³/h

Features

Flexiable layout

· According to the size of the customer's site, the inclined belt can be 20°, 28°, 45°, the silo can be high or low frame, the batching station can be arranged as " 一" or "L" type, the loading ramp or flat loading is optional.

High efficiency and reliability

· Inclined belt batching plant has high efficiency and stability, low failure rate

High extensibility

· It can be used as commercial batching plant and project batching plant

High-performance mixer, high-efficiency mixing

· Core patented shaft end sealing technology, automatic compensation, reliable sealing, easy maintenance with lower cost

· Interrupted spiral arrangement of stirrer, large axial circulation, small radial circulation, central vortex stirring, three-way mixing and boiling type mixing, increasing efficiency by 20%

· Optimal L/D ratio design, equipped with curved large opening discharge door, short discharge time, 3s lessmixing time.

SYMC controller, safe and reliable

· Multi-language operation interface

· Distributed network architecture or the entire control system with full digital transmission

· The upper computer and lower computer communicate through Ethernet, with a speed of 100000kbps

Adaptive learning, ensuring high accuracy

· Multi-gear and multi-speed aggregates, adaptive adjustment of each weighing mode and control curve

· Self-learning algorithm for weighing parameters, with automatic correction of dropout

· Self-learning water retaining advance, combined with jittering water retaining technology

Modular design, fast installation and disassembly

· Pre-installation of all electrical elements and pipelines, reducing the installation workload on site

· The main building is designed according to the standard container size, optimizing the maintenance space under the condition of occupying the least packing space.

Specs & Compare

Aggregate Capacity
Category of Aggregate
Feeding Mode
Material Discharging Height
Max. Aggregate Size
Motor Power
Nominal Capacity of Mixer
Rated Power
Reference Weight
Silo Capacity
Theoretic Productivity
HZS180F8
4×25 m³
4
Conveyor
4.2 m
80 mm
2×55 kW
3000 L
250 kW
106 T
4×200 T
180 m³/h
