HOT SALE! Highly efficiency, Low fuel consumption!

Operating Weight:
1820kg
Engine Power:
11.2/2400 kW/rpm
Bucket Capacity:
0.04m³
Conditions:

City construction, landscape engineering, and farmland improvements for narrow and complicated working condition

  • The third Generation load-sensitive System
  • High Reliability, First-class core configuration


Click for the online view of the excavator → 【 SY16C 】

SY16C mini excavator features high efficiency, low consumption and a comfortable operating environment. The 1.82 ton excavator has a wide range of applications in narrow spaces including forest, farm and indoors. Benefits & Features: High Performance & Reliability, Compact Design for Narrow Zone Operations, Strong Adaptability to Various Situations, Safe & Environmentally Friendly.

SY16CSY16CSY16CSY16C

Engine
Engine model
Yanmar 3TNV74F
Rated power
11.2/2400 kW/rpm
Max.torque
48.5-51.8/1800 N·m/rpm
Displacement
0.993 L
Emission standard
Tier 4 final
Operation Range
Operating weight
1820 kg
Max. digging height
3665 mm
Max. dumping height
2635 mm
Max. digging depth
2360 mm
Max. vertical digging depth
2215 mm
Max. digging reach
4000 mm
Min. swing radius
1655 mm
Height at min.swing radius
2745 mm
Max.ground clearance of blade up
310mm
Max.depth of blade down
320mm
Dimensions
Transport length
3575 mm
Transport width
980/1350 mm
Transport height
2420 mm
Upper width
980 mm
Blade height
270 mm
Tail swing radius
920 mm
Min. ground clearance
180 mm
Undercarriage/Working Device
Std. track shoe width
230 mm
Bucket capacity
0.04 m³
Track gauge
750/1120 mm
Roller gauge
1220 mm
Boom length
1810 mm
Arm length
1130 mm
Performance
Travel speed
3.7/2.1 km/h
Swing speed
10 rpm
Gradeability
30°
Ground pressure
29.1 kPa
Bucket digging force
15.2 kN
Arm digging force
9.2 kN
Fuel tank capacity
23 L
Hydraulic tank capacity
21 L
